[Aymericr]

What does this PR do?

Localizes the column, chimney and elevator inspectors. Part of #621. main (4772056, with #1180 and #1181) is merged in with a normal merge commit. The compiled en and en-XA catalogs and the literal baseline were regenerated with i18n:extract, i18n:literals update and i18n:compile. i18n/pseudo-surfaces.ts keeps both sides' scenes and surfaces, without duplicates. Reviewed entries stay at 85 per locale, and release-check finds no draft compiled in. Stored scene data is unchanged.

• Option arrays become lazy descriptors, translated where they render:
  • column proportions and support styles;
  • chimney types;
  • elevator door, door panel and shaft styles.
• Overflow. The column, chimney and other option cards wrap their labels instead of truncating them.
• Preset names are translated at display time: the chimney style presets (Brick, Modern, Round) and the column preset dropdown (Straight Round, Square Block…). Core's COLUMN_PRESETS and CHIMNEY_PRESET_LABELS stay English.
• Elevator copy is converted: "Stop {stopOrder}", access and service, door timing, and shaft and cab dimensions.
• Audit. New column-panel and chimney-panel surfaces. They run on the furnished project with a seeded column and a chimney on the roof segment. The elevator has no surface: elevators belong to the building, the layers panel doesn't list them, and they can only be selected in the viewport.
• Catalogs. 185 new messages. zh-CN, fr, es and ja drafts are fuzzy with Review: required, so they show English until reviewed. The literal baseline drops by 188, from 1,139 on main to 951.

Dormer, skylight and solar panel are in #1183, to keep each PR reviewable.

How to test

1. bun run i18n:check passes after the merge, with 2,989 entries per locale awaiting review. bun scripts/i18n.ts release-check --base origin/main passes too.
2. Run bun dev with ?lang=en-XA. Select a column, a chimney and an elevator: every inspector is bracketed and accented, the option cards wrap, and the column preset dropdown's choices are localized.
3. Run bunx turbo run build --filter=@pascal-app/nodes (the app loads nodes from dist), then bun run i18n:pseudo-audit -- column-panel chimney-panel: both pass. I ran this. The audit doesn't open the native preset <select>.
4. Tests I ran after the merge, with core and nodes rebuilt first:
   • packages/nodes: 5,027 pass, 1 skip.
   • packages/editor bun test src: 2,704 pass.
   • apps/editor bun test lib: 74 pass.
   • bun test scripts/: 131 pass.
   • The editor, nodes and app type checks are clean, and bun run check reports no errors.

Still English after this PR

• Elevator inspector. It is converted but wasn't exercised by the audit, for the reason above.
• Placement copy. The chimney tool's preview and placement copy is tool copy, not inspector copy.
• Remaining inspectors: dormer, skylight and solar panel ([Maintainer] i18n: migrate the dormer, skylight and solar panel inspectors #1183), then vents, fences and MEP ([Maintainer] i18n: migrate the vent, fence and MEP inspectors #1185). Construction dimension and block also remain.

Screenshots / screen recording

en-XA, captured by i18n:pseudo-audit (UTC, metric). The images are served from the image-only branch cursor/i18n-audit-screenshots-8160, which is never merged.

Column (support styles wrap rather than truncate):

Chimney:

Checklist

• I've tested this locally with bun dev
• My code follows the existing code style (run bun check to verify)
• I've updated relevant documentation (if applicable)
• This PR targets the main branch



---

Note

Low Risk
Display-only i18n wiring and catalog updates; scene data and preset keys are unchanged, with regression coverage via pseudo-audit for column and chimney.

^{Reviewed by Cursor Bugbot for commit 09e91b8. Bugbot is set up for automated code reviews on this repo. Configure here.}

[chatgpt-codex-connector]

Codex Review Summary

This comment shows the latest Codex review activity on this pull request.

Review	Status	Commit	Review trigger
📝 Code Review	✅ Completed 2026-10-27T16:44:25.140337Z	1d6d704	PR opened

ℹ️ About Codex in GitHub

Your team has set up Codex to review pull requests in this repo. Reviews are triggered when you

• Open a pull request for review
• Mark a draft as ready
• Comment "@codex review" or "@codex security review".

Codex reacts with 👀 while any review is running, comments if it has suggestions, and reacts with 👍 once all reviews finish with no findings.

[chatgpt-codex-connector]

💡 Codex Review

Here are some automated review suggestions for this pull request.

Reviewed commit: 1d6d7046ee

ℹ️ About Codex in GitHub

Your team has set up Codex to review pull requests in this repo. Reviews are triggered when you

• Open a pull request for review
• Mark a draft as ready
• Comment "@codex review".

If Codex has suggestions, it will comment; otherwise it will react with 👍.

Codex can also answer questions or update the PR. Try commenting "@codex address that feedback".

[chatgpt-codex-connector]

Localize the actual column preset choices

When the editor uses a non-English locale and the user opens this dropdown, only the new “Apply preset…” placeholder is localized; each choice below still renders option.label directly from the English-only COLUMN_PRESETS data (Straight Round, Square Block, etc.). Define UI-language descriptors for those preset names, as this change already does for chimney presets, and translate them with i18n._ when rendering the options.

Useful? React with 👍 / 👎.

[Aymericr]

Tooling cross-review at 87050df: APPROVE

No P0/P1/P2.

• Stored data: column presets are translated only at display through COLUMN_PRESET_LABELS. presetUpdates still strips label, so nothing translated is written. I checked all 15 English messages against COLUMN_PRESETS[*].label and they match exactly. Proportion and support-style options keep their values, and only the labels are messages. Chimney and elevator are display only.
• Numbers: no # plurals, no , number formats and no toFixed changes.
• Catalogs: +185 entries per locale, all fuzzy with Review: required. Reviewed stays at 85 per locale and drafts are 2711 for each locale.
• No Security areas are touched.

Findings

• P3: once [Maintainer] i18n: editor-side inspector panels and 3D overlay scope #1180 merges, this PR will conflict in i18n/pseudo-surfaces.ts (adjacent insertions) and in the compiled en/en-XA messages.ts. Re-run i18n:extract after rebasing. literal-baseline.json also conflicts with [Maintainer] i18n: migrate the cabinet inspectors #1181 and [Maintainer] i18n: migrate the vent, fence and MEP inspectors #1185.

Checks run locally (Node 22; core and nodes dist rebuilt at this head):

• Tests: editor 2704 pass; nodes 5026 run, 0 fail; scripts/i18n*.test.ts 56 pass.
• tsc clean for editor and nodes. Biome clean.
• i18n:check PASS, catalogs in sync. release-check --base origin/main shows no reviewed regression and no draft compiled in. i18n-literals check reports no new literals.

CI at this SHA: Changed paths, quality, cli-smoke and Cursor Bugbot all succeeded.

[Aymericr]

Tooling cross-review at 09e91b8: APPROVE

This is a delta check since 87050df. No findings.

• The head is a single merge commit with parents 87050df and 4772056 (the [Maintainer] i18n: migrate the cabinet inspectors #1181 squash).
• Compared with a clean git merge-tree of the two parents, only the four conflicted files differ:
  • en messages.ts and en-XA messages.ts: regenerated.
  • i18n/pseudo-surfaces.ts: both sides kept (the cabinet imports, scene and surfaces plus the column/chimney ones), 38 surfaces with no duplicates.
  • i18n/literal-baseline.json: regenerated.
• The .po files are the clean auto-merge. A fresh i18n:extract plus i18n-literals update leaves git status clean.
• Literal baseline 1139 → 951 is real:
  • 951 = 1139 minus this PR's own 188 removals, all in the chimney, column and elevator panels.
  • The head baseline exactly equals main's minus those 188, with nothing added and nothing removed elsewhere.
  • literal-allowlist.json, scripts/ and .github/ are unchanged against main, and the PR adds no i18n-ignore.
  • i18n-literals check reports no new literals.
• i18n:check passes, with 2989 drafts for each locale. Reviewed stays at 85 per locale. release-check --base origin/main shows no reviewed regression and no draft compiled in.
• Local checks (Node 22; core and nodes rebuilt at this head):
  • Tests: nodes 5028 run, 0 fail; editor 2704 pass.
  • tsc clean for editor, nodes and apps/editor.
• CI at this SHA: Changed paths, quality, cli-smoke and Cursor Bugbot all succeeded.
• Main has since moved to 410069d (core: author_scene revisions leave a derived surface's holes to the reconciler #1187, author_scene in core only). That merges cleanly with this head.
