What does this PR do?

This is the first of the remaining inspector PRs: the editor-side panels, plus one editor fix the node inspectors depend on. Part of #621. main (with #1179) is merged in with a normal merge commit. Stored scene data is unchanged.

• i18n scope inside 3D overlays (fix). drei's <Html> renders its children in a separate React root, which sees none of the surrounding context. Any component inside it that called usePascalI18n() got the default English scope instead of the ?lang= or <Editor locale> scope. That affected the node action menu, the 3D room pills, the selection summary and the cursor HUDs.

  • New components/editor/localized-html.tsx is a drop-in Html that re-provides the caller's scope. The editor's 23 drei Html imports switch to it; the usages themselves don't change.
  • It's exported as LocalizedHtml. The node packages' own Html labels (cabinet, dormer, fence, MEP) switch to it in their inspector PRs.
  • The three nodes tests and one editor test that drop Html labels by element type now match LocalizedHtml.

• Node action menu. All buttons: Move, Duplicate, Delete, Group/Ungroup, Rotate, Curve, Cut out, Find in catalog, Edit mesh. The door and window Open/Close and the Play/Stop button are one ICU select. Shortcut key names in its tooltips ("Backspace") use the existing key messages.

• Riser diagram. Title, legend, empty state, and the close button, which now has an accessible name. Core's marker labels (2" P-trap, 2" VTR, raw fitting types) stay English in core, where MCP reads them. The panel words them at display time, and fittings use the shared editor.inspector.option.* names ("Sanitary tee" rather than sanitary-tee).

• Procedural item inspector. Header, back, parts, position, and the fallback error copy. Recipe and part labels are authored data and stay as written.

• MEP run HUD. "Length: {field} m" is one message around the input (messageWithSlot), plus the placeholder and the Tab hint.

• Tooling P3 from [Maintainer] i18n: room-name and count follow-ups #1179: ungrouped counts. The remaining [Maintainer] i18n: migrate properties and inspector panels #1174 counts now use a plain {…Count} value inside the plural, as [Maintainer] i18n: room-name and count follow-ups #1179 did, so they read 1234 like main rather than 1,234:

  • door and window counts;
  • stair risers;
  • surveyed lines;
  • "shared with # room(s)";
  • "The floor's # roofs".

  The existing drafts were rewritten with the same substitution.

• Audit. New node-action-menu surface: a door's action menu with the Delete tooltip. The riser diagram has no surface, because the standalone app's toolbar doesn't include its toggle (hosts that use ViewToggles do).

• Catalogs. 35 new messages, 5 changed. zh-CN, fr, es and ja drafts are fuzzy with Review: required, so they show English until reviewed.

How to test

1. bun run i18n:check passes, with 2,561 entries per locale awaiting review.
2. Run bun dev, open a project with ?lang=en-XA, and select a door. The floating action menu, its tooltips (including the key name) and the door's Open button are bracketed and accented. Before this PR they were English.
3. bun run i18n:pseudo-audit over every migrated surface (all except home, settings and the whole-editor sweep): all 30 pass, including the new node-action-menu. I ran this.
4. Tests I ran:
   • packages/editor bun test src: 2,704 pass.
   • packages/nodes: 5,025 pass, 1 skip.
   • bun test scripts/: 131 pass.
   • Editor and nodes type checks are clean, and bun run check reports no errors.

Still English after this PR

• Node inspectors: cabinets, column, chimney, elevator, vents, dormer, skylight, solar panel, fences and MEP. These come next, split by kind so each PR stays reviewable.
• Also still English: construction dimension and block, external plugin copy, command messages, material names and unit suffixes.

Screenshots / screen recording

en-XA, captured by i18n:pseudo-audit (UTC, metric). The images are served from the image-only branch cursor/i18n-audit-screenshots-8160, which is never merged.

Node action menu on a door, with the Delete tooltip and its key name:

Room panel (door and window counts, action menu inside the 3D overlay):

Roof panel:

Stair panel (riser counts):

Checklist

• I've tested this locally with bun dev
• My code follows the existing code style (run bun check to verify)
• I've updated relevant documentation (if applicable)
• This PR targets the main branch



[chatgpt-codex-connector]

Codex Review Summary

This comment shows the latest Codex review activity on this pull request.

Review	Status	Commit	Review trigger
📝 Code Review	✅ Completed 2026-10-27T15:49:15.381173Z	913961e	PR opened

ℹ️ About Codex in GitHub

Your team has set up Codex to review pull requests in this repo. Reviews are triggered when you

• Open a pull request for review
• Mark a draft as ready
• Comment "@codex review" or "@codex security review".

Codex reacts with 👀 while any review is running, comments if it has suggestions, and reacts with 👍 once all reviews finish with no findings.

[Aymericr]

Tooling cross-review at 913961e: APPROVE

No P0/P1/P2.

• Stored data: display only. Node action menu, mechanism button, riser diagram, procedural inspector and run HUD copy are translated where they render; nothing translated reaches updateNode or MCP. The procedural inspector still shows core/zod error messages as-is.
• LocalizedHtml: drei Html with one PascalI18nProvider around its children. That adds a context provider and an i18n.retain() ref-count on mount. There is no useFrame and no extra state. drei still re-renders its root only when the children change, as before, and props and ref pass through. All 3D overlays and tests in packages/editor are switched over.
• Counts P3: doors, windows, risers, surveyed lines, shared with # room(s) and The floor's # roofs now use plain {xCount} strings, so 1234 shows ungrouped, as on main. No new # plurals and no , number formats. Plain placeholders pass through unformatted (I checked Lingui directly).
• Catalogs: +35 entries per locale, all fuzzy with Review: required. Reviewed stays at 85 per locale and drafts are 2561 for each locale.
• No Security areas are touched.

Findings

• P3: riser fitting markers in English change from the raw enum (sanitary-tee) to the prettified inspector option (Sanitary tee). It's display only and arguably better, but it differs from main.
• P3 (follow-up): packages/nodes overlays still import drei Html (measurement, zone renderer, dormer guides, MEP tools). A component inside those roots that calls usePascalI18n() itself gets the default scope. They should move to LocalizedHtml once this merges.
• P3: some # plurals from earlier migrations still group at 1000 or more: guide/scan counts, # register(s), # object(s) selected, the Roof/Staircase segment default names, and # tool(s) in apps/editor.

Checks run locally (Node 22; core and nodes dist rebuilt at this head):

• Tests: editor 2704 pass; nodes 5026 run, 0 fail; core 6166 run, 0 fail; mcp 1338 pass; scripts/i18n*.test.ts 56 pass.
• tsc clean for editor, nodes and apps/editor. Biome shows 13 warnings, the same as main.
• i18n:check PASS, catalogs in sync. release-check --base origin/main shows no reviewed regression and no draft compiled in. i18n-literals check reports no new literals.

CI at this SHA: Changed paths, quality, cli-smoke and Cursor Bugbot all succeeded.

After this merges, the compiled en/en-XA messages.ts in #1181, #1182, #1183 and #1185 will conflict (regenerate them). #1181 and #1182 also conflict in i18n/pseudo-surfaces.ts (adjacent insertions). The .po files and literal-baseline.json merge cleanly with this PR.
