dash-mui-charts — MUI X charts for Dash

Interactive MUI X charts, tree views and time pickers for Plotly Dash.

13 components · full Python type hints · clicks, zoom, selection and edits as Dash callbacks · dark mode · Community and Pro tiers.

Documentation · Discord · YouTube · GitHub

Maintained by Pip Install Python LLC.

---

Overview

dash-mui-charts wraps MUI X Charts, MUI X Tree View and the MUI X Date & Time Pickers' TimeClock as first-class Dash components. Author charts in Python, and get every interaction back as a callback property.

• 13 components — nine chart types, three tree views, and a clock-face time picker.
• Callbacks-first — clickData, axisClickData, highlightedItem, hoverIndex, zoomData, selection and edit events all arrive as Dash inputs; controlled props (highlightedItem, expandedItems, value, …) work in both directions for synchronized, cross-chart UIs.
• Dark mode by construction — components watch the Mantine color-scheme attribute and re-theme live.
• Functions-as-props — axis valueFormatter and alert formatters accept {'function': 'name', 'options': {...}} resolved from a JS registry, mirroring the dash-mantine-components pattern.
• Community and Pro tiers — Community features need no license; zoom/pan, sliders, toolbars, brush, Heatmap and TreeViewPro extras light up with a MUI X Pro license key.

Installation

pip install dash-mui-charts

Requires dash>=3.3. See Dash compatibility for the tested matrix.

Quick Start

from dash import Dash, html
from dash_mui_charts import LineChart, PieChart

app = Dash(__name__)

app.layout = html.Div([
    LineChart(
        series=[
            {'data': [2, 5, 3, 8, 1, 9], 'label': 'Sales'},
            {'data': [1, 3, 2, 5, 4, 6], 'label': 'Costs'},
        ],
        xAxis=[{'data': ['Jan', 'Feb', 'Mar', 'Apr', 'May', 'Jun'], 'scaleType': 'band'}],
        height=300,
    ),
    PieChart(
        data=[
            {'id': 0, 'value': 35, 'label': 'Marketing'},
            {'id': 1, 'value': 25, 'label': 'Engineering'},
            {'id': 2, 'value': 20, 'label': 'Sales'},
            {'id': 3, 'value': 20, 'label': 'Support'},
        ],
        height=300,
    ),
])

if __name__ == '__main__':
    app.run(debug=True)

Documentation

📚 muicharts.2plot.dev

41 pages of live, interactive examples — every chart family with working callbacks, two props playgrounds, and an API reference whose props tables are generated from the components' own metadata. Every docs page also serves an LLM-friendly version at /<page>/llms.txt.

Run it locally:

git clone https://github.com/pip-install-python/dash-mui-charts.git
cd dash-mui-charts
pip install -r requirements.txt
# markdown2dash pins gunicorn<22, against the CVE-driven gunicorn>=23 floor in
# requirements.txt. pip cannot resolve both, so it installs without its
# dependency graph — every one of them is in requirements.txt already.
pip install --no-deps markdown2dash==0.1.2
pip install -e .
python run.py    # http://127.0.0.1:7666

Components

Component	Category	What it is	Tier
LineChart	Charts	Line/area charts, biaxial axes, reference lines, zoom/pan, brush	Community / Pro
BarChart	Charts	Vertical/horizontal bars, stacking, bar labels, dataset mode, zoom	Community / Pro
CandlestickChart	Charts	OHLC candlesticks with volume overlay and reference lines	Community / Pro
PieChart	Charts	Pie, donut, and nested pies with controlled highlighting	Community
ScatterChart	Charts	Scatter plots, z-axis color mapping, voronoi interaction	Community
CompositeChart	Charts	Scatter + line series layered on one surface, multi-axis	Community / Pro
Heatmap	Charts	Matrix visualization with continuous/piecewise color scales	Pro
SparklineChart	Charts	Compact inline charts for dashboards, KPI cards and tables	Community
LiveTradingChart	Charts	Real-time streaming OHLCV simulation with forecast and alerts	Community / Pro
TreeView	Trees	Data-driven RichTreeView: selection, expansion, inline label editing	Community
SimpleTreeView	Trees	JSX-driven tree for navigation sidebars and static hierarchies	Community
TreeViewPro	Trees	Drag-reorder, lazy loading, per-item slider and kebab controls	Pro
TimeClock	Pickers	Inline clock-face time picker	Community

MUI X Pro licensing

dash-mui-charts itself is MIT. Pro-tier features run on MUI X Pro, which requires a commercial license from MUI — pass your key to any component via the licenseKey prop:

import os
from dash_mui_charts import BarChart

BarChart(
    licenseKey=os.environ['MUI_PRO_API_KEY'],
    series=[...],
    xAxis=[{'data': [...], 'scaleType': 'band', 'zoom': {'minSpan': 8}}],
    showSlider=True,   # Pro: zoom slider
)

Without a key, Pro features render with MUI's unlicensed watermark — components degrade, they never crash. Community features never need a key.

API reference

The /api page lists every prop of all 13 components, generated from the components' own metadata so it always matches the installed version. The props you will meet everywhere:

Prop	Type	Description
id	str	Dash callback identity — available on every component
licenseKey	str	MUI X Pro key — enables Pro features per component
clickData / axisClickData	dict	Callback outputs: what was clicked, with series/axis context
highlightedItem	dict	Controlled highlight — works as callback input AND output
hoverIndex / hoverValue	—	Sparkline hover stream for synchronized displays
selectedItems / expandedItems	—	Tree selection/expansion — controlled or uncontrolled
sx	dict	MUI system styling passed straight to the underlying component

Dash compatibility

The package targets Dash 3.3 and up; the documentation site needs Dash 4.1+ (its llms.txt engine pins dash>=4.1). Both floors are verified, not assumed, in GitHub Actions on every push and PR:

• the docs site boots and smoke-tests on Dash 4.1.0 / 4.2.0 / 4.3.0 / 4.4.1 (Python 3.10–3.13), rebuilding the component bundle and Python wrappers from source in each cell;
• the wheel installs into a clean venv with nothing but Dash present on Python 3.9 → 3.13, plus a dedicated dash==3.3.0 floor install;
• the production Docker image is built, booted secretless, and probed by the same network battery that checks the live site after every deploy.

python scripts/smoke_test.py     # the per-version harness, standalone

Development

git clone https://github.com/pip-install-python/dash-mui-charts.git
cd dash-mui-charts

# JS toolchain (only needed when changing src/lib/components)
npm install
npm run build            # webpack bundle + regenerated Python wrappers
npm run validate-init    # all 13 components generated and importable

# Python
pip install -r requirements.txt
pip install --no-deps markdown2dash==0.1.2   # pins gunicorn<22; see above
pip install -e .
python run.py            # docs on :7666

# Test
pytest tests/                                # 80 checks, zero secrets by design
python scripts/smoke_test.py                 # routes, layouts, JS parse
python scripts/route_parity.py --charts-only # every live example, id and callback intact
python scripts/check_release.py              # version drift, stale bundle, packaging

# Build a distribution
python -m build

The React sources in src/lib/components/*.react.js are the source of truth — the Python classes in dash_mui_charts/ are generated from their PropTypes by dash-generate-components. The built bundle and wrappers are committed so git-based deploys (Render) work without a node toolchain.

After editing src/lib/components/*.react.js you must run npm run build and commit the regenerated bundle and wrappers in the same commit — check_release.py compares git commit timestamps and flags a bundle older than its source. The version lives in two files: package.json (which setup.py reads) and dash_mui_charts/package-info.json (which __version__ reads, regenerated by the build); check_release.py fails if they drift.

Releasing

Tag-driven. git tag -a vX.Y.Z && git push origin vX.Y.Z runs release.yml: it asserts the tag matches package.json, re-runs the consistency and smoke checks, builds, publishes to PyPI over OIDC trusted publishing (no API token stored anywhere), and opens a GitHub Release with that version's CHANGELOG section attached. A workflow_dispatch dry run publishes to TestPyPI instead.

Deployment

The documentation site runs at muicharts.2plot.dev on Render. The repo ships a render.yaml blueprint and Dockerfile — create a Render Blueprint from the repo, fill the sync: false secrets in the dashboard, point the muicharts.2plot.dev CNAME at the service, and it auto-deploys on push to main with a /healthz health check.

The canonical origin lives in exactly one place — DEFAULT_BASE_URL in lib/constants.py (override per-environment with APP_BASE_URL). templates/index.html carries __CANONICAL_ORIGIN__ tokens that run.py substitutes at startup, so the canonical link, og:url, the JSON-LD, sitemap.xml, robots.txt and the llms.txt links cannot drift apart.

Requirements

• Python >= 3.9 (the documentation site itself needs >= 3.10 — see below)
• Dash >= 3.3 (the documentation site needs >= 4.1)
• Node.js >= 18 — only to rebuild the JS bundle
• A MUI X Pro license — only for Pro-tier features

The package needs only Python 3.9+ and Dash 3.3+; that range is verified in CI. Running the documentation site from source additionally needs Python 3.10+ (python-frontmatter imports typing.TypeGuard) and Dash 4.1+. Neither floor applies to pip install dash-mui-charts.
