HyperRender

The only Flutter HTML renderer with CSS float layout.

Renders HTML, Markdown, and Quill Delta using a single custom RenderObject — not a widget tree. Drop-in replacement for flutter_html and flutter_widget_from_html. Ships with CSS float, Flexbox, Grid, CJK typography, crash-free text selection, and zero JS dependencies.

Quick Start · Why Switch? · Features · API · Benchmarks

---

⚡ Quick Start

dependencies:
  hyper_render: ^1.1.0

import 'package:hyper_render/hyper_render.dart';

// Works. Sanitization is ON by default — safe for user content.
HyperViewer(
  html: articleHtml,
  onLinkTap: (url) => launchUrl(Uri.parse(url)),
)

That's it. No configuration required. Works for news articles, emails, documentation, and CJK content out of the box.

---

🎬 See It In Action

CSS Float — Magazine Layout	Ruby / Furigana	Crash-Free Text Selection
Text flows around floated images — no other Flutter HTML library can do this	Furigana centered above base glyphs with full Kinsoku line-breaking	Select across headings, paragraphs, and table cells — tested to 100K chars

Advanced Tables	vs. flutter_widget_from_html	Virtualized Mode
colspan, rowspan, auto-scaling, W3C 2-pass column algorithm	Same HTML — side by side	Only visible sections are built and painted — smooth at any document length

---

🔀 Why Switch from FWFH / flutter_html?

Most Flutter HTML libraries map each tag to a Flutter widget — Column, Row, Padding, Wrap, RichText. A 3,000-word article becomes 500+ deeply nested widgets, and then:

What you need	flutter_html / FWFH	HyperRender
float: left/right	❌ Impossible	✅
Text selection (large docs)	❌ Crashes	✅ Crash-free
Ruby / Furigana	❌ Shows raw text	✅
<details>/<summary>	❌	✅ Interactive
CSS Variables var()	❌	✅
Flexbox / Grid	⚠️ Partial	✅ Full
Box shadow & filters	❌	✅
Scroll FPS (25K-char article)	~35–45 fps	60 fps
RAM usage	15–28 MB	~8 MB

Float is not a missing feature you can add. To wrap text around a floated image, the layout engine needs every fragment's coordinates before composing the adjacent text. A widget tree where each Column owns its own layout simply cannot share that geometry — there is no algorithm that fixes this without replacing the widget tree entirely.

That is exactly what HyperRender does: one RenderObject, one coordinate system, one layout pass.

---

✨ Features

🌟 CSS Float — Magazine Layouts

HyperViewer(
  html: '''
    <article>
      <img src="photo.jpg"
           style="float: left; width: 180px; margin: 0 16px 8px 0; border-radius: 8px;" />
      <h2>Magazine Layout</h2>
      <p>This text flows around the floated image — exactly like a real browser.
         No other Flutter library can render this correctly.</p>
    </article>
  ''',
)

---

✅ Crash-Free Text Selection

HyperViewer(
  html: longArticleHtml,
  selectable: true,              // default
  showSelectionMenu: true,       // Copy / Select All
  selectionHandleColor: Colors.blue,
)

One continuous span tree = selection across headings, paragraphs, and table cells. Tested to 100,000-character documents in CI without crashes.

---

🈶 Professional CJK Typography

HyperViewer(
  html: '''
    <p style="font-size: 20px; line-height: 2;">
      <ruby>東京<rt>とうきょう</rt></ruby>で
      <ruby>日本語<rt>にほんご</rt></ruby>を学ぶ
    </p>
  ''',
)

Furigana renders centered above base characters. Kinsoku shori (line-breaking rules) applied across the full line — not truncated at widget boundaries like every other library.

---

🎨 CSS Variables, Flexbox, Grid

// CSS custom properties
HyperViewer(html: '''
  <style>
    :root { --brand: #6750A4; --gap: 16px; }
    .card { background: var(--brand); padding: calc(var(--gap) * 1.5);
            border-radius: 12px; color: white; }
  </style>
  <div class="card">Themed with CSS custom properties</div>
''')

// Flexbox navigation bar
HyperViewer(html: '''
  <div style="display: flex; justify-content: space-between;
              align-items: center; gap: 16px; background: #1976D2;
              padding: 12px; border-radius: 8px; color: white;">
    <strong>MyApp</strong>
    <div style="display: flex; gap: 20px;">
      <span>Home</span><span>Blog</span><span>About</span>
    </div>
  </div>
''')

// CSS Grid
HyperViewer(html: '''
  <div style="display: grid; grid-template-columns: 1fr 2fr 1fr; gap: 12px;">
    <div style="background: #E3F2FD; padding: 16px;">Sidebar</div>
    <div style="background: #F3E5F5; padding: 16px;">Main</div>
    <div style="background: #E8F5E9; padding: 16px;">Aside</div>
  </div>
''')

---

📊 Multi-Format Input

// HTML
HyperViewer(html: '<h1>Hello</h1><p>World</p>')

// Quill Delta JSON
HyperViewer.delta(delta: '{"ops":[{"insert":"Hello\\n"}]}')

// Markdown (CommonMark)
HyperViewer.markdown(markdown: '# Hello\n\n**Bold** and _italic_.')

// Custom CSS injection
HyperViewer(
  html: articleHtml,
  customCss: 'body { font-size: 18px; line-height: 1.8; } a { color: #6750A4; }',
)

---

🛡️ Sanitization — Safe for User Content

XSS protection is on by default. You opt out, not in.

// ✅ Safe by default — strips <script>, on* handlers, javascript: URLs
HyperViewer(html: userGeneratedContent)

// ✅ Custom allowlist
HyperViewer(
  html: userContent,
  allowedTags: ['p', 'a', 'img', 'strong', 'em', 'ul', 'li'],
)

// ⚠️ Disable only for trusted internal HTML
HyperViewer(html: trustedCmsHtml, sanitize: false)


---

🔭 Hybrid WebView Fallback

// Automatic — HtmlHeuristics detects complex HTML and routes it to WebView
HyperViewer(
  html: maybeComplexHtml,
  fallbackBuilder: (context) => WebViewWidget(controller: _webViewController),
)

// Manual check
if (HtmlHeuristics.isComplex(html)) {
  // Use WebView
}

---

🖼️ Visual Effects

Because HyperRender controls the paint cycle directly, it supports effects that standard Flutter widgets make difficult:

• Glassmorphism: backdrop-filter: blur(10px)
• Box & text shadows: multi-layer, with spread and blur
• CSS filters: filter: blur(4px) brightness(1.2) contrast(0.8)
• Gradients: background: linear-gradient(to right, #6a11cb, #2575fc)
• Dashed / dotted borders: border-style: dashed | dotted
• High-DPI images: automatic FilterQuality.medium

---

🧮 Formula / LaTeX

// Built-in Unicode renderer (zero deps)
FormulaWidget(formula: r'E = mc^2')
FormulaWidget(formula: r'\frac{-b \pm \sqrt{b^2 - 4ac}}{2a}')

// Plug in flutter_math_fork for full LaTeX
FormulaWidget(
  formula: r'\int_{-\infty}^{\infty} e^{-x^2} dx = \sqrt{\pi}',
  customBuilder: (context, formula) => Math.tex(formula),
)

Also works as a Quill Delta embed: {"insert": {"formula": "E = mc^2"}}.

---

📸 Screenshot Export

final captureKey = GlobalKey();

HyperViewer(html: articleHtml, captureKey: captureKey)

final pngBytes = await captureKey.toPngBytes();
final image   = await captureKey.toImage();

---

📖 Interactive <details> / <summary>

<details>
  <summary>Click to expand</summary>
  <p>HyperRender is the only Flutter HTML library that supports this interactively.</p>
</details>

---

🌐 RTL / BiDi

<p dir="rtl">هذا نص عربي من اليمين إلى اليسار</p>
<p dir="ltr">Back to left-to-right text.</p>

---

📊 Benchmarks

Measured on iPhone 13 (iOS 17) + Pixel 6 (Android 13) with a 25,000-character article. Run flutter run --release benchmark/performance_test.dart to reproduce.

Metric	flutter_html	flutter_widget_from_html	HyperRender
Flutter widgets created	~600	~500	3–5 chunks
Parse time	420 ms	250 ms	95 ms
RAM usage	28 MB	15 MB	8 MB
Scroll FPS	~35	~45	60
float: left/right	❌	❌	✅
Selection on large docs	⚠️ Limited	❌ Crashes	✅
Ruby / Furigana	❌	❌	✅
CSS Variables	❌	❌	✅
Glassmorphism / Filters	❌	❌	✅

"Widgets created": flutter_html / FWFH produce one Flutter widget per HTML tag. HyperRender splits the document into ~3–5 RenderHyperBox chunks and paints each directly to Canvas — the tag count never maps to widget count.

---

📖 API Reference

HyperViewer

HyperViewer({
  required String html,
  String? baseUrl,                          // Resolve relative URLs
  String? customCss,                        // Inject extra CSS
  bool selectable = true,                   // Enable text selection
  bool sanitize = true,                     // XSS protection (default: ON)
  List<String>? allowedTags,               // Custom sanitizer allowlist
  HyperRenderMode mode = HyperRenderMode.auto, // sync | virtualized | auto
  Function(String)? onLinkTap,
  HyperWidgetBuilder? widgetBuilder,        // Inject Flutter widgets by tag
  WidgetBuilder? fallbackBuilder,           // Shown when HtmlHeuristics.isComplex()
  WidgetBuilder? placeholderBuilder,        // Async loading state
  GlobalKey? captureKey,                    // Screenshot export
  bool enableZoom = false,
  bool showSelectionMenu = true,
  String? semanticLabel,
  HyperViewerController? controller,        // Programmatic scroll + anchor jump
  void Function(Object, StackTrace)? onError,
})

HyperViewer.delta(delta: jsonString, ...)
HyperViewer.markdown(markdown: markdownString, ...)

Custom Widget Injection

HyperViewer(
  html: htmlContent,
  widgetBuilder: (context, node) {
    if (node is AtomicNode && node.tagName == 'iframe') {
      final src = node.attributes['src'] ?? '';
      if (src.contains('youtube.com')) return YoutubePlayer(url: src);
    }
    return null; // fall through to default rendering
  },
)

HyperViewerController — Anchor Navigation

final _ctrl = HyperViewerController();

HyperViewer(html: articleHtml, controller: _ctrl)

// Jump to any #anchor in the document
_ctrl.jumpToAnchor('section-2');
_ctrl.scrollToOffset(1200);

HtmlHeuristics

HtmlHeuristics.isComplex(html)              // any of the below
HtmlHeuristics.hasComplexTables(html)       // colspan > 3 or deeply nested tables
HtmlHeuristics.hasUnsupportedCss(html)      // position:fixed, clip-path
HtmlHeuristics.hasUnsupportedElements(html) // canvas, form, select, input

SmartTableWrapper

SmartTableWrapper(
  tableNode: myTableNode,
  strategy: TableStrategy.horizontalScroll, // fitWidth | autoScale | horizontalScroll
  minScaleFactor: 0.6,
)

FormulaWidget

FormulaWidget(
  formula: r'\frac{-b \pm \sqrt{b^2-4ac}}{2a}',
  style: TextStyle(fontSize: 18),
  customBuilder: (context, f) => Math.tex(f), // optional flutter_math_fork hook
)

---

🏗️ Architecture

HTML / Delta / Markdown
        │
        ▼
   ADAPTER LAYER          ← HtmlAdapter · DeltaAdapter · MarkdownAdapter
        │
        ▼
UNIFIED DOCUMENT TREE     ← BlockNode · InlineNode · AtomicNode · RubyNode
                               TableNode · FlexContainerNode · GridNode
        │
        ▼
  CSS RESOLVER            ← specificity cascade · var() · calc() · inheritance
        │
        ▼
SINGLE RenderObject       ← BFC · IFC · Flexbox · Grid · Table · Float
                               Canvas painting · continuous span tree
                               Kinsoku · perfect text selection

Key design choices:

• Single RenderObject — the whole document is one RenderBox; float layout and crash-free selection are only possible because every fragment's coordinates live in one coordinate system
• O(1) CSS rule lookup — rules are indexed by tag/class/ID; lookup is constant-time regardless of stylesheet size
• RepaintBoundary per chunk — ListView.builder splits large documents into chunks, each with its own GPU layer; cross-chunk repaints never trigger
• One-shot image listeners — ImageStreamListener self-removes on success and error; no listener leaks

---

⚠️ When NOT to Use HyperRender

HyperRender is a content renderer, not a browser. Use something else for:

Need	Better Choice
Execute JavaScript	webview_flutter
Interactive web forms	webview_flutter
Rich text editing	super_editor, fleather
position: fixed, canvas elements	webview_flutter (via fallbackBuilder)
Maximum CSS property count, no float/CJK need	flutter_widget_from_html

---

📦 Extension Packages

Package	Purpose	Status
hyper_render_core	UDT model, CSS resolver, design tokens	✅ Stable
hyper_render_html	HTML adapter	✅ Stable
hyper_render_markdown	Markdown adapter	✅ Stable
hyper_render_highlight	Syntax highlighting for <code>	✅ Stable
hyper_render_clipboard	Image copy / share	✅ Stable

Use the convenience hyper_render package (this one) to get all of the above in one dependency.

---

🗺️ Roadmap

✅ Shipped (v1.0 → v1.1)

CSS float · Flexbox · Grid · CSS Variables · calc() · Kinsoku + Ruby · <details> · RTL/BiDi · Quill Delta · Markdown · XSS sanitization · Screenshot export · HtmlHeuristics fallback · View virtualization · Design tokens · Dark mode · Performance monitoring

🔜 v1.2 — Stability & CSS polish

• Memory-pressure handling (WidgetsBindingObserver — auto-evict caches on low-memory signal)
• Full SVG renderer (currently shows placeholder)
• video_player / audio integration

🔮 v2.0+ — Plugin ecosystem & animation

• hyper_render_media package — extract media layer so core stays zero-dep
• CSS @keyframes / transition execution (currently parsed but not animated)
• hyper_render_devtools first working release (UDT inspector, computed-style panel)
• hyper_render_export — full-document PDF and high-res image export

Full details → doc/ROADMAP.md

---

🤝 Contributing

git clone https://github.com/brewkits/hyper_render.git
cd hyper_render && flutter pub get
flutter test                    # all tests must pass
cd example && flutter run       # run the demo app

Read the Architecture Decision Records and Contributing Guide before submitting PRs.

---

📄 License

MIT — see LICENSE.

---

⭐ Star History

If HyperRender saves you from WebView overhead, a star goes a long way:

---

👤 Author & Maintainer

HyperRender is designed and maintained by brewkits.

Built to solve a real problem: Flutter's rich-text ecosystem either uses WebView (heavy) or flutter_widget_from_html (no float, no CJK). HyperRender is the third option — a native single-RenderObject engine that runs at 60 FPS and handles real-world editorial HTML.

If this library helps your product ship faster, consider sponsoring development or leaving a ⭐ on GitHub.

---

Built with care for Flutter developers who push the platform.

Get Started · Demo App · Report a Bug · pub.dev
