BatteryRemapper (LSPosed Module)

BatteryRemapper is a modern Xposed/LSPosed module paired with an intuitive Material management application. It recalibrates Android's battery reporting scale, mapping a customizable physical battery window (by default 20% – 80%) into a full 0% – 100% display layer across your status bar, quick settings, and lock screen.

By restricting daily operational usage to these optimal chemical thresholds, BatteryRemapper significantly minimizes lithium-ion degradation, prevents high-voltage stress, and dramatically extends the lifespan of your device's non-removable battery.

---

🚀 Features

• Interactive Material Manager: Clean, responsive UI with full Material 3 dynamic styling, system bar edge-to-edge support, and automatic dark/light theme integration.
• Customizable Physical Range: Adjust your physical charge ceiling and floor using an interactive dual-thumb range slider (e.g., 20% – 80%, 15% – 85%, or any custom bounds).
• Live Hook Detection: Real-time bidirectional IPC handshake that probes System UI to immediately indicate whether the module hook is Active, Inactive, or Checking.
• Linear Scale Remapping: Smoothly translates physical battery percentage to your configured scale across the status bar, notification shade, and lock screen.
• Smart Hysteresis Battery Saver Automation:
  • Triggers ON: Automatically enables Battery Saver mode when your remapped percentage reaches 20% or below.
  • Triggers OFF: Automatically turns Battery Saver mode OFF once remapped battery charges past 50%.
  • Hysteresis Dead-Zone: Maintains existing state between 21% – 50% when unplugged to prevent battery state flickering.
  • Charging Bypass: Instantly disengages Battery Saver upon connecting a charger (AC, USB, or Wireless) for maximum charging performance.
  • Toggle Control: Can be enabled or disabled on demand from the app.
• Automated Low-Battery Shutdown Protection:
  • Optional safety sequence that initiates a system-level 30-second countdown when reaching your chosen trigger level (defaulting to 0% remapped).
  • Smart Charger Abort: Plugging in a charger instantly aborts the shutdown sequence and dismisses the alert.
  • Dismissal Safeguard: Dismissing the alert dialog temporarily suppresses repeated countdowns for the remainder of the discharge cycle.
• One-Click System UI Restart: Dedicated root-enabled action (su -c killall com.android.systemui) with confirmation dialog to instantly apply changes without a full device reboot.
• Seamless Shared IPC (SettingsProvider): Rootless, real-time configuration sharing between the manager app and the System UI hook via an internal Content Provider.
• About & Credits Hub: Dedicated About screen with dynamic version tracking, repository links, license details, and developer/contributor credits.

---

⚙️ LSPosed Setup Configuration

To ensure the module functions correctly, configure its target scope inside the LSPosed Manager (or compatible Xposed framework interface).

Target Scope:

• System UI (com.android.systemui)

Important

The module is specifically scoped to run inside com.android.systemui. This ensures your status bar, quick setting tiles, and lock screen graphics reflect your custom 0–100% scale while the underlying Android system server and kernel continue to track raw physical metrics accurately.

---

📈 How the Math Works

The display percentage is dynamically calculated from the physical percentage using linear normalization:

$$\text{Display %} = \text{round}\left( \frac{\text{Physical %} - \text{Min}}{\text{Max} - \text{Min}} \times 100 \right)$$

Default Mapping Example (Physical 20% – 80% $\rightarrow$ Display 0% – 100%):

Actual Physical Battery	Displayed Status Bar Battery	System Behavior & States
80% and above	100%	Upper charge ceiling cap
65%	75%	Intermediate remapped value
51%	51%	Battery Saver turns OFF if unplugged
35%	25%	Normal operational range
25%	8%	Low battery threshold — Battery Saver is ON
20% and below	0%	Lower charge floor — triggers shutdown countdown (if enabled)

---

⚠️ Notes & Considerations

• Stepped Percentage Drops: Due to mathematical scaling of a compressed physical range (e.g., 60 points mapped to 100 points), the status bar percentage will occasionally step by 2% (e.g., jumping from 77% to 75%). This is natural linear rounding behavior.
• Direct Kernel Node Reads: Hardware monitor applications or terminal commands that bypass the Android framework to read raw kernel nodes directly (e.g., /sys/class/power_supply/battery/capacity) will reflect the raw physical percentage.

---

📱 Supported Devices & Environment

• Android Version: Android 10+ (API 29+).
• Root & Framework: Magisk or KernelSU/Apatch with Zygisk, and LSPosed (or compatible modern Xposed framework).
• Root Permission (Optional): Required only for the in-app "Restart System UI" quick action; the remapping and automation hooks themselves operate root-free inside System UI.
• ROM Compatibility:
  • AOSP & Custom ROMs: Pixel, LineageOS, crDroid, Evolution X, Infinity X, Axion AOSP, Motorola, Sony, etc.
  • OEM Skins: Xiaomi HyperOS / MIUI, Samsung One UI, OnePlus/OPPO/Realme OxygenOS & ColorOS, Vivo/iQOO OriginOS & FuntouchOS.
  • Supports status bar customizations including circles, dotted icons, landscape pills, and text-only battery styles.

---

📥 Download & Installation

You can get the latest pre-compiled release from either source:

• 📦 GitHub Releases: Download Latest APK
• 🧩 LSPosed Module Repository: BatteryRemapper Module Page

---

👥 Credits

• Developer: Dhangofa
• Contributor: Rillwyn

---

💬 Community & Support

• Telegram Discussion Group: BatteryRemapper Chat
• Developer Telegram: @dhangofa
• GitHub Issues: BatteryRemapper Issues

---

📄 License

This project is open-source under the terms of the MIT License.
